Hydraulic Mini Loader/ Dumper 500kg
Features:
- Variable speed forward & reverse
- Centrifugal clutch steering.
- Hydraulic tipping & digging operation
- Heavy duty bin
- Tracks made from heavy duty rubber for safe use on paved surfaces.
- Ground clearance 62mm
- Turning distance 82cm
- Maximum working pressure 200BAR
- Colour #RAL3020
Description
Technical Specifications:
| Model No. | 750DLH |
| Engine Make | Loncin OHV |
| Engine Displacement | 270cc / 9HP |
| Engine Type | Single Cylinder 4 Stroke Air Cooled |
| Fuel Tank Capacity | 10 Litres |
| Maximum Carry Weight | 500kg at maximum lift height |
| Maxium Bucket Load | 200KG |
| 30% Gradient Max | 375KG |
| Lift Height | 1.2M |
| Maximum Speed | 6km/hour |
| Start System | Recoil |
| Fuel Consumption Est. | 1.5 L/hr |
| Engine Oil Specification | 10W/30 Winter – 10W/40 Summer |
| Engine Oil Capacity | 2 Litres |
| Hydraulic Oil Specification | ISO 46 |
| Hydraulic Oil Capacity | 33 Litres |
| Fuel Specification | ULP 91 |
| Noise Level | 92 DBA |
| Track Width | 180mm |
| Bin Dimensions | 1000L x 700W x 450H mm |
| Dimensions (foot rest in up position) | 2330L x 850W x 1200H mm |
| Shipping Dimensions | 1820L x 900W x 1350H mm |
| Weight | 430kg |
| Shipping Weight | 450kg |
